Wichard 13/32" Diameter Twisted Shackle w/ Captive Pin

Item #

1425

Product Description

Wichard 13/32" Diameter Twisted Shackle w/ Captive Pin

Features

  • Weight - 0.375 Lbs

  • Working load - 3351 Lbs

  • Breaking load - 9171 Lbs

  • A - 2 29/32 inch

  • B - 51/64 inch

  • C - 7/16 inch

  • Diameter - 25/64 inch

    <b.description< b="">

  • Captive pin twisted shackle forged in grade 316L stainless steel

  • The pin is connected to the body at all times even when opened

  • The pin is locked into one of the indentations

  • No risks of loose due to vibrations

  • Outstanding working and breaking loads

  • Single handed operation for more safety

    Applications

  • Perfect for application where a 90° angle twist setup is required

  • Often used to attach an unarticulated part (block on a rail) or on purchases

    Material

  • Grade 316L stainless steel
