Product Description
Lewmar #16 Standard Bronze Two Speed Winch
Lewmar has created a winch range that incorporates many exciting disciplines. All brought together with a blend of traditional skills and high technology, which are reflected in the outstanding quality of Lewmar’s standard winches. Besides the technical innovation and high performance criteria involved, there’s also the aesthetic appearance and finish to consider. The range shown here achieves just that with sizes ranging from 6-44, one– or two-speed gearing and three superb finishes including classical bronze. All of which is supported by a comprehensive range of winch spares.
Specifications
Finish - Bronze
Gear Ratio 1st/2nd - 1:1/2:1
Power Ratio 1st/2nd - 7.9:1/16:1
Weight(lb) - 7
Dimensions
Drum Diameter D(in) - 2 5/8
Base Diameter B(in) - 4 3/4
Height H (in) - 4 7/16
Line Entry L (in) - 2 3/16
Mounting Instructions
5 x M6 (1/4 in) c'sk head screws on 94mm (3 11/16in) PCD. Lewmar recommend that the rope enters onto the drum at an angle of 5º to 10º to the base axis of the winch. To achieve this angle it may be necessary to use a base wedge when installing the winch. This product is Made to Order.
